| Quantity: | |
|---|---|
Material: TP316/L, TP304/L, S32205, S32750, Alloy 825/N08825, Alloy 400/ N04400, Alloy 625/ N06625
Outer Diameter: 1/4“， 3/8”，1/2“
Wall Thickness: 0.035”，0.049“，0.065”
Hole count: Single/Multi Core
Length : According to customers’ needs, up to 10000m
Standard: ASTM A269/A213/A789/B704/B163,etc.
Certificate: ISO/CCS/DNV/BV/ABS, etc.
Inspection: NDT; Hydrostatic test
Package: Wooden or iron reel
Where the control line used ?
1 . Control tubing in oil and gas well
2 . Instrument tubing
3 . Chemicl injection tubing line
4 . Pre-insulated tubing
5 . Electric heating or steam heating tubing line
6 . Hater tubing line
 |  |
Material | ASTM A269 Chemical Composition % Max | ||||||||||
C | Mn | P | S | Si | Cr | Ni | Mo | N B | Nb | Ti | |
TP304 | 0.08 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-11.0 | ^ | ^ | ^. | ^ |
TP304L | 0.035 | 2 | 0.045 | 0.03 | 1 | 18.0-20.0 | 8.0-12.0 | ^ | ^ | ^ | ^ |
TP316 | 0.08 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | ^ | ^ | ^ |
TP316L | 0.035 | 2 | 0.045 | 0.03 | 1 | 16.0-18.0 | 10.0-15.0 | 2.00-3.00 | ^ | ^ | ^ |
TP321 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.0-19.0 | 9.0-12.0 | ^ | ^ | ^ | 5C -0.70 |
TP347 | 0.08 | 2 | 0.045 | 0.03 | 1 | 17.0-19.0 | 9.0-12.0 | 10C -1.10 | ^ | ||
Plastic Packaging Materials | Abbreviation | Temperature℃ |
Ethylene Tetrafluoroethylene | ETFE | -60℃~150℃ |
Fluoronated Ethylene Propylene | FEP | -110℃~200℃ |
High Density Polyethylene | HDPE | -60℃~100℃ |
Perfluoroalkoxy | PFA | -80℃~260℃ |
Modified Polypropylene | PP | 30℃~150℃ |
Polyvinylidene Fluoride | PVDF | -30℃~150℃ |
Thermoplastic Vulcanizating | TPV | -30℃~150℃ |
Nylon11 | PA11 | -30℃~150℃ |
MTSCO has been supplying control line to the heat exchanger/ oil and gas industry for more than a decade. In recent years, we have continued to make breakthroughs in the field of coiled tubing, downhole control lines, and chemical injection control lines. Our control line has been successfully used in kinds of heat exchanger, certain harsh subsea and downhole conditions, and through continuous research and development, is able to meet the stringent quality requirements of oil field and other industries.
